Wio Terminal - SAMD51 with WiFi and 2.4" LCD

Item no.:
102991299
€39.87 €32.95
In stock

Customer Reviews

Rated with 9.2 from 10 - Based on 564 reviews

Wio Terminal is complete product with Arduino, WiFi, LCD, sensors and many interfaces.

It has an ATSAMD51-based microcontroller with wireless connectivity supported by Realtek RTL8720DN, a 2.4” LCD Screen, onboard IMU (LIS3DHTR), microphone, buzzer, microSD card slot, light sensor, infrared emitter, 5-way switch and buttons. All of these practical add-ons are carefully housed in a compact enclosure, making it an efficient and product-ready product.

Wio Terminal is equipped with Raspberry Pi 40-pin GPIO. It can be mounted on a Raspberry Pi as a slave device. The GPIO connector can also be used for extension boards. The USB host function allows connection of a keyboard or mouse with a USB OTG adapter.

Programming is supported by Arduino, Micropython, ArduPy, AT Firmware and Visual Studio Code.

More information is available in Get Started and on the website of Seeed Studio.

Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account

Bundles

  • Wio Terminal - SAMD51 with WiFi and 2.4" LCD 102991299 Antratek Electronics
    X1
    Wio Terminal - SAMD51 with WiFi and 2.4" LCD
    +
    USB-C Power Adapter 3A KA1801A-BULK Antratek Electronics
    X1
    USB-C Power Adapter 3A
    USB-C Power Adapter 3A

    Power supply adapter and charger with USB-C connector.

    It is suitable for Raspberry Pi 4.

    More information is available on the website of KEYU.

    Excl. BTW:€42.90 €39.89

    Incl. BTW:€51.91 €48.90

    25% discount on accessories


    1*Wio Terminal - SAMD51 with WiFi and 2.4" LCD + 1*USB-C Power Adapter 3A
  • Wio Terminal - SAMD51 with WiFi and 2.4" LCD 102991299 Antratek Electronics
    X1
    Wio Terminal - SAMD51 with WiFi and 2.4" LCD
    +
    Wio Terminal Chassis - Battery (650mAh) 103990564 Antratek Electronics
    X1
    Wio Terminal Chassis - Battery (650mAh)
    Wio Terminal Chassis - Battery (650mAh)

    The Wio Terminal Battery Chassis is an extension board for Wio-Terminal Dev Board as it provides an external power source for Wio Terminal to enhance its portability and compactness.

    It has a 650mAH rechargeable lithium polymer battery, battery charging/discharging status LED, 4 Grove Analog/Digital Ports, 1 Grove I2C Port, and 1 Grove UART Port, as well as the ABS enclosure for aesthetic and protection. The board has a BQ27441-G1A fuel gauge for LiPo batteries. There is also the same Raspberry Pi 40-pin compatible GPIO at the back of the Wio Terminal Battery Chassis for more add-ons.

    More information is available on the website of Seeed Studio.

    Excl. BTW:€56.90 €53.46

    Incl. BTW:€68.85 €65.41

    5% discount


    1*Wio Terminal - SAMD51 with WiFi and 2.4" LCD + 1*Wio Terminal Chassis - Battery (650mAh)
  • Wio Terminal - SAMD51 with WiFi and 2.4" LCD 102991299 Antratek Electronics
    X1
    Wio Terminal - SAMD51 with WiFi and 2.4" LCD
    +
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS 114992728 Antratek Electronics
    X1
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS

    Wio Terminal Chassis with LoRa-E5 and GNSS is a LoRaWAN communication extension board for Seeed Wio Terminal Dev Board.

    It is embedded with the LoRa-E5 STM32WLE5JC Module, which is the world-first combo of LoRa RF and MCU chip into one single tiny chip. It is powered by ARM Cortex-M4 core and Semtech SX126X LoRa chip, supports both LoRaWAN and LoRa protocol on the worldwide frequency and (G)FSK, BPSK, (G)MSK, and LoRa modulations.

    The GNSS module is the Quectel L76-LB. It supports concurrent reception of GPS, GLONASS, BeiDou and QZSS. With 33 tracking channels, 99 acquisition channels and 210 PRN channels, it can acquire and track any mix of GPS, GLONASS (or BeiDou) and SBAS signals.

    With Wio-Terminal and Wio Terminal Chassis you can easily build the a powerful compact and cost-effective IoT device, like for example LoRaWAN GPS Tracker or LoRaWAN Field Tester.

    LoRa antenna is included.

    More information is available on the website of Seeed Studio.

    Excl. BTW:€62.90 €59.09

    Incl. BTW:€76.11 €72.30

    5.01% discount


    1*Wio Terminal - SAMD51 with WiFi and 2.4" LCD + 1*Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS
  • Wio Terminal - SAMD51 with WiFi and 2.4" LCD 102991299 Antratek Electronics
    X1
    Wio Terminal - SAMD51 with WiFi and 2.4" LCD
    +
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS 114992728 Antratek Electronics
    X1
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS
    Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS

    Wio Terminal Chassis with LoRa-E5 and GNSS is a LoRaWAN communication extension board for Seeed Wio Terminal Dev Board.

    It is embedded with the LoRa-E5 STM32WLE5JC Module, which is the world-first combo of LoRa RF and MCU chip into one single tiny chip. It is powered by ARM Cortex-M4 core and Semtech SX126X LoRa chip, supports both LoRaWAN and LoRa protocol on the worldwide frequency and (G)FSK, BPSK, (G)MSK, and LoRa modulations.

    The GNSS module is the Quectel L76-LB. It supports concurrent reception of GPS, GLONASS, BeiDou and QZSS. With 33 tracking channels, 99 acquisition channels and 210 PRN channels, it can acquire and track any mix of GPS, GLONASS (or BeiDou) and SBAS signals.

    With Wio-Terminal and Wio Terminal Chassis you can easily build the a powerful compact and cost-effective IoT device, like for example LoRaWAN GPS Tracker or LoRaWAN Field Tester.

    LoRa antenna is included.

    More information is available on the website of Seeed Studio.

    +
    Wio Terminal Chassis - Battery (650mAh) 103990564 Antratek Electronics
    X1
    Wio Terminal Chassis - Battery (650mAh)
    Wio Terminal Chassis - Battery (650mAh)

    The Wio Terminal Battery Chassis is an extension board for Wio-Terminal Dev Board as it provides an external power source for Wio Terminal to enhance its portability and compactness.

    It has a 650mAH rechargeable lithium polymer battery, battery charging/discharging status LED, 4 Grove Analog/Digital Ports, 1 Grove I2C Port, and 1 Grove UART Port, as well as the ABS enclosure for aesthetic and protection. The board has a BQ27441-G1A fuel gauge for LiPo batteries. There is also the same Raspberry Pi 40-pin compatible GPIO at the back of the Wio Terminal Battery Chassis for more add-ons.

    More information is available on the website of Seeed Studio.

    Excl. BTW:€86.85 €81.60

    Incl. BTW:€105.09 €99.84

    5% discount


    1*Wio Terminal - SAMD51 with WiFi and 2.4" LCD + 1*Wio Terminal LoRaWAN Chassis with LoRa-E5 and GNSS + 1*Wio Terminal Chassis - Battery (650mAh)
