SN50v3-CB - NB-IoT/LTE-M Digital Sensor Node
-
Buy 10 and save 10%:
€65.29 €53.96
Product description
Dragino SN50v3-CB is a NB-IoT and LTE-M Digital Sensor Node for Internet of Things. It has 5V output to power an external sensor, 3 interrupt inputs (or 3 digital I/O), 3 one-wire, 1 UART and 1 I2C interfaces. The node will convert the values to NB-IoT or LTE-M wireless data and send to IoT platform via a NB-IoT/LTE-M network.
You can use various IoT Servers and different uplink methods including MQTT, MQTTs, UDP and TCP.
The sensor node uses Quectel BG95-NGFF Multi-band LTE Cat M1/Cat NB2 module with GPS which can be used in most European countries. It has a card slot for an NB-IoT/LTE-M SIM card.
This device supports BLE for easy configuration and wireless OTA to update the firmware.
SN50v3-CB is powered by 8500mAh Li-SOCI2 battery for many years of use. It has an external antenna and an IP66 enclosure with a waterproof M12 cable hole for an external sensor.
More information is available in the datasheet and user manual.
